ALL TERRAIN, ALL THE TIME

Kuvittele tämä: KTM 690 ENDURO R murisee kierrosten noustessa, kun esikaupunkialue jää hitaasti taaksesi. Edessä kirkas LED-valo valaisee tien halki aikaisen aamun sumun, kun syöksyt kohti seuraavaa sorapätkää. Hetkeä myöhemmin lennät jo kohti erämaata, siirtyen asfaltista hiekalle vaivattomasti – ilman hikipisaraakaan. Tässä piilee KTM 690 ENDURO R:n viehätys: rajaton monipuolisuus.

ENGINE

Design: 1-cylinder, 4-stroke engine
Displacement: 692.7 cm³
Power: 79 PS
Torque: 73 Nm
Transmission: 6-speed
CO₂ emissions: 99 g/km
Cooling: Liquid cooled
Engine cylinder: Single cylinder
EMS: Keihin EMS with RBW, twin ignition
Engine oil: Motorex Power Synth SAE 10W-50
Engine stroke: 4-Stroke
Silencer: Stainless steel primary and secondary silencer

CHASSIS

Frame design: Chromium-Molybdenum steel trellis frame, powder coated
Rear subframe design: Self-supporting plastic tank
Chain: 520 X-Ring
Steering head angle: 62.3°
Trail: 120 mm
Wheelbase: 1506 mm
Wheelbase tolerance: ±15 mm

BRAKES

Front brake: Disc brake
Rear brake: Disc brake
Front brake disc diameter: 300 mm
Rear brake disc diameter: 240 mm
Brake disc diameters (front/rear): 300 / 240 mm

SUSPENSION

Front suspension: WP XPLOR-USD, Ø 48 mm
Rear suspension: WP XPLOR with Pro-Lever linkage
Suspension travel (front): 265 mm
Suspension travel (rear): 250 mm
Front suspension adjustment: Compression and rebound adjustable
Rear suspension setting: Compression (high and low speed), rebound and preload adjustable

DIMENSIONS

Seat height: 935 mm
Tank capacity (approx.): 13.3 l
Ground clearance: 265 mm
Weight (without fuel): 152 kg
Weight fully fueled: 162 kg

WHEELS

Front wheel diameter: 21"
Rear wheel diameter: 18"
Front wheel width: 1.85"
Rear wheel width: 2.5"
Wheels: 1.85 x 21"; 2.5 x 18"
